| Brand Name: | GENY |
| Model Number: | YC1893D-ICT |
| MOQ: | 1 |
| Price: | negotiate rates |
| Payment Terms: | T/T, L/C, D/P, T/T |
| Supply Ability: | 5 sets / 1 months |
| YCS-103-250 | YCS-103-600 | YCS-103-1200 | YCS-103-2500 | |
| Voltage | ||||
| Test voltage output (Phase-Neutral) | 3×(24V – 288V) or customized | |||
| Power of the voltage output | 3×100VA | 3×250VA | 3×500VA | 3×1000VA |
| Resolution | Better than 0.01% of full scale value of range | |||
| Setting accuracy | Better than 0.05% at the final range value | |||
| Stability | Better than 0.005%/h (integration time 150 s) | |||
| Load regulation from 0-max. load | < 0.01% | |||
| Distortion factor | < 0.3% for linear resistance load | |||
| Harmonics | 2nd – 21st free programmable | |||
| Current | ||||
| Test current output | 3×(1mA – 100A) | |||
| Power of the current output | 3×150VA | 3×350VA | 3×750VA | 3×1500VA |
| Resolution | Better than 0.01% of full scale value of range | |||
| Setting accuracy | Better than 0.05% at the final range value | |||
| Stability | Better than 0.005%/h (integration time 150 s) | |||
| Load regulation from 0-max. load | < 0.01% | |||
| Distortion factor | < 0.3% for linear resistance load | |||
| Harmonics | 2nd – 21st free programmable | |||
| Phase angle | ||||
| Range | 0 -- 360° | |||
| Resolution | 0.01° | |||
| Setting accuracy | 0.1° | |||
| Frequency | ||||
| Range | 45Hz – 65Hz | |||
| Resolution | 0.01Hz | |||
| Voltage Supply |
3×220/380V±10% or customized 50/60Hz±2Hz |
|||
| Ambient temperature | -10°C -- +40°C | |||
| Relative humidity | 35% -- 85% | |||
1. High accuracy and high stability output
2. With RS232 interface for automatic operation
3. With keyboard for manual operation (optional).
4. 2nd – 21st harmonic, output amplitude and degree can be programmed.
5. Aluminum alloy materials, light and strong, prevent corrosion.
6. With the protect function of overload, short voltage circuit and open current circuit.
7. Simple control software, easy for operation
1. Nation-level utility companies
2. Governmental bureaus of metrology
3. Big energy meter manufacturers
1. High quality product
2. High power output (max. voltage power: 1000VA, current power: 1500VA)
3. Extremely high power stability
4. Distortion factor less than 0.3% for linear resistance load
