High-Precision Programmable Power Source for Energy Meter Calibration

Name: High-Precision Programmable Power Source for Energy Meter Calibration
Brand: Guangzhou GENY Electric Co., Ltd
SKU: YCS-103
Availability: InStock

Brand Name:	GENY
Model Number:	YCS-103
MOQ:	1 pcs
Price:	Negotiation
Payment Terms:	L/C,T/T,D/P
Supply Ability:	100/Year

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO, CE

Document:

Catalogue——Meter Test S...m..pdf

Harmonics:

2nd – 21st Free Programmable

Distortion Factor:

< 0.3% For Linear Resistance Load

Voltage Supply:

3×220/380V±10% Or Customized 50/60Hz±2Hz

Test Voltage Output (Phase-Neutral):

3×(24V – 288V) Or Customized

Packaging Details:

Plywood case

Supply Ability:

100/Year

Highlight:

programmable power source for calibration

stationary power source with precision

energy meter calibration power supply

Product Description

High-Precision Programmable Power Source for Energy Meter Calibration

Advanced programmable power source designed specifically for precision energy meter calibration with exceptional accuracy and stability.

Key Features

High-accuracy output with exceptional stability
RS232 interface for automated operation
Optional keyboard support for convenient manual operation
Programmable 2nd-21st harmonic output with amplitude and phase angle settings
Durable aluminum alloy construction - lightweight, robust, and corrosion-resistant
Integrated protection against overload, short-circuit voltage, and open-circuit current conditions
User-friendly control software for simple and efficient operation

Primary Applications

National utility companies
Government metrology and calibration authorities
Large-scale energy meter manufacturers

Competitive Advantages

Premium-quality design and manufacturing
High power capacity:
- Maximum voltage power: 1000 VA
- Maximum current power: 1500 VA
Outstanding power output stability
Ultra-low distortion factor (<0.3%) under linear resistive load conditions

Technical Specifications

Model	YCS-103-250	YCS-103-600	YCS-103-1200	YCS-103-2500
Voltage Specifications
Test voltage output (Phase-Neutral)	3×(24V - 288V) or customized
Power of the voltage output	3×100VA	3×250VA	3×500VA	3×1000VA
Resolution	Better than 0.01% of full scale value of range
Setting accuracy	Better than 0.05% at the final range value
Stability	Better than 0.005%/h (integration time 150 s)
Load regulation from 0-max. load	< 0.01%
Distortion factor	< 0.3% for linear resistance load
Harmonics	2nd - 21st free programmable
Current Specifications
Test current output	3×(1mA - 100A)
Power of the current output	3×150VA	3×350VA	3×750VA	3×1500VA
Resolution	Better than 0.01% of full scale value of range
Setting accuracy	Better than 0.05% at the final range value
Stability	Better than 0.005%/h (integration time 150 s)
Load regulation from 0-max. load	< 0.01%
Distortion factor	< 0.3% for linear resistance load
Harmonics	2nd - 21st free programmable
Additional Parameters
Phase angle range	0 - 360°
Phase angle resolution	0.01°
Phase angle setting accuracy	0.1°
Frequency range	45Hz - 65Hz
Frequency resolution	0.01Hz
Voltage supply	3×220/380V±10% or customized 50/60Hz±2Hz
Ambient temperature	-10°C - +40°C
Relative humidity	35% - 85%
