| Brand Name: | GENY |
| Model Number: | YC1893D |
| MOQ: | 1 PCS |
| Payment Terms: | L/C,T/T,D/P |
| Supply Ability: | 3 PCS per month |
1. Measures mechanical, electronic mechanical, and electronic meters (automatic, semi-automatic, manual).
2. Meters: 3P4W, 3P3W, 1P2W.
3. Modes: active, reactive, cross-connected reactive power.
4. Simultaneous measurement of same-spec meters with different constants.
5. Automatic rotor mark positioning for mechanical meters.
6. Starting and creeping tests.
7. Protection against overload, short circuit, open circuit.
8. Lightweight, strong, corrosion-resistant aluminum alloy.
9. Windows-compatible software (2000/XP/7/8/10) with modules for error, harmonic, demand, and influence tests.
1. High-quality product
2. Over 18 months warranty
3. Highest accuracy class: 0.01/0.02
4. Extremely high power stability
5. Timing error test
6. Influence tests (voltage, frequency, harmonics)
7. RS232 and Ethernet ports in each meter position
|
Technical Speciation |
|
|
Max Number Of Meter Positions |
6 |
|
Accuracy Class |
0.01% / 0.02% |
|
Power Source |
YCS-103-X |
|
Standard Meter |
ZERA: COM3003 RADIAN: RD33-233 EMH/MTE: K2006 GENY: SZ03A-K8 |
|
Scanning Head |
YCG-S Series |
|
Voltage |
|
|
Test voltage output(Phase-Neutral) |
3x(40V~500V)(or customized) |
|
Power of the voltage output |
3x200VA |
|
Resolution |
Better than 0.001% of full scale value of range |
|
Stability |
Better than 0.002% /h (integration time 150s) |
|
Load regulation from 0~max. load |
Better than 0.01% |
|
Distortion factor |
Better than 0.05% for linear resistance load |
|
Harmonic |
2nd~21st free programmable |
|
Current |
|
|
Test current output |
3x (1mA~120A) max. to 230A |
|
Power of the current output |
3x300VA |
|
Resolution |
Better than 0.001% of full scale value of range |
|
Stability |
Better than 0.002% /h (integration time 150s) |
|
Load regulation from 0~max. load |
Better than 0.01% |
|
Distortion factor |
Better than 0.05% for linear resistance load |
|
Harmonic |
2nd~21st free programmable |
|
Phase angle |
|
|
Range |
0~360⁰ |
|
Resolution |
0.01⁰ |
|
Frequency |
|
|
Range |
45Hz~65Hz |
|
Resolution |
0.001Hz |
|
Error display |
|
|
Type of error display |
Red LED |
|
Resolution of error displays |
8 digitals |
|
Other |
|
|
Voltage supply |
3x220/380V±10%(or customized) 50/60Hz ±2Hz |
|
Ambient temperature |
-10°C~+40°C |
|
Relative humidity |
35%~85% |
