| Brand Name: | GENY |
| Model Number: | YC1893D |
| MOQ: | 1 |
| Price: | negotiate rates |
| Payment Terms: | T/T, L/C, D/P, T/T |
| Supply Ability: | 5 sets / 1 months |
|
Voltage |
3 × 220V±10% |
|
Frequency |
50 / 60Hz ± 2Hz |
|
Power capacity |
>6k VA |
|
Ambient temperature |
-10°C -- +40°C |
|
Relative humidity |
35% -- 85% |
|
Voltage output |
|
|
Test voltage output (Phase-Neutral) |
3 × (24V – 300V) |
|
Power of the voltage output |
3 × 1000VA |
|
Resolution |
Better than 0.01% of full scale value of range |
|
Setting accuracy |
Better than 0.05% at the final range value |
|
Stability |
Better than 0.005%/h (integration time 150 s) |
|
Load regulation from 0-max. load |
Better than 0.01% |
|
Distortion factor |
Better than 0.3% for linear resistance load |
|
Harmonics |
2nd – 21st free programmable |
|
Current output |
|
|
Test current output |
3 × (0.3mA – 20A) |
|
Power of the current output |
3 × 1500VA |
|
Resolution |
Better than 0.01% of full scale value of range |
|
Setting accuracy |
Better than 0.05% at the final range value |
|
Stability |
Better than 0.005%/h (integration time 150 s) |
|
Load regulation from 0-max. load |
Better than 0.01% |
|
Distortion factor |
Better than 0.3% for linear resistance load |
|
Harmonics |
2nd – 21st free programmable |
|
Phase angle |
|
|
Range |
0 -- 360° |
|
Resolution |
0.01° |
|
Setting accuracy |
0.1° |
|
Frequency |
|
|
Range |
45Hz – 65Hz |
|
Resolution |
0.01Hz |
