| Brand Name: | GENY |
| Model Number: | YC99T-3C |
| MOQ: | 1 |
| Price: | negotiate rates |
| Payment Terms: | T/T, L/C, D/P, T/T |
| Supply Ability: | 5 sets / 1 months |
| Voltage | |
| AC Voltage Range | 57.7V-660V |
| Power of the Voltage output | MAX.30VA |
| Resolution | 0.01% |
| Accuracy | 0.1% |
| Stability | 0.01%/120s |
| Distortion factor | 0.2% |
| Current | |
| Test current output | 1A-50A |
| Power of the current output | Max. 100VA |
| Resolution | 0.01% |
| Accuracy | 0.05% |
| Stability | 0.01%/180s |
| Distortion factor | < 0.3% for linear resistance load |
| Phase angle | |
| Range | 0 -- 360° |
| Resolution | 0.01° |
| Accuracy | 0.2° |
| Frequency | |
| Range | 40Hz – 70Hz |
| Resolution | 0.005Hz |
| Pulse output | |
| Harmonic Output | 2-63 |
| Pulse input | |
| Input channel | 3 |
| Input frequency | Max. 20Hz |
| Other | |
| Voltage Supply | 220V±15% /110V±15% (optional) |
| Ambient temperature | 20°C -- 30°C |
| Relative humidity | ≤85% |
| Dimensions (W×H×D) (mm) | 500 X 440 X 180 |
| Weight (kg) | 46(5C)/22(3C) |
