| Brand Name: | GENY |
| Model Number: | YC1893R |
| Payment Terms: | L/C, T/T, D/P |
| Supply Ability: | 100 |
YC1893R series is developed by our company with international advanced level of high-grade equipment. The overall accuracy levels up to 0.01 grades. It Is designed for institute of metrology, laboratory, EPRI and EEM equipment plants. It is mainly used to establish primary standards or the standards meter for the working standard .
This is a Stationary Three-phase Energy Meter Test System described here can simultaneously test 1…3, three-phase or single-phase electric energy meters, in which are 2-wire, 3-wire and 4-wire meters for active and reactive energy with accuracy of 0.1%, 0.2%, 0.5%, 1.0%, 2.0%.
The Meter Test System has following features and functions
| Voltage | 240/415 V AC supply (+5% & -10%) or customized |
| Frequency | 50/60Hz ±2Hz |
| Power capacity | > 3 × 6kVA |
| Ambient temperature | -10°C … +40°C |
| Relative humidity | 35% … 95% |
| System Grounding | Neutral solidly grounded |
| Surge protection level | ≥ 10 kV/120 Joules (10/1000µs) |
| Voltage | |
| Test voltage output (Phase-Neutral) | 3× (24V - 500V) or customized |
| Power of the voltage output | 3×100VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.003%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 41st free programmable |
| Current | |
| Test current output | 3× (1mA - 120A) |
| Power of the current output | 3×150VA |
| Resolution | Better than 0.01% of full scale value of range |
| Setting accuracy | Better than 0.05% at the final range value |
| Stability | Better than 0.003%/h (integration time 150 s) |
| Load regulation from 0-max. load | < 0.01% |
| Distortion factor | < 0.3% for linear resistance load |
| Harmonics | 2nd - 41st free programmable |
| Phase angle | |
| Range | 0 -- 360° |
| Resolution | 0.01° |
| Setting accuracy | 0.1° |
| Frequency | |
| Range | 45Hz - 65Hz |
| Resolution | 0.01Hz |
1.Pioneering Innovation:
Over 20 years of leadership in Electric Energy Meter measurement technology.
2.Expert R&D Team:
Committed to advancing Electric Energy Meter test instruments.
Catering to the diverse needs of a global clientele.
3.Professional Excellence:
Specialized training for all staff members.
Emphasis on high professional quality and skill.
4.ISO9001 Quality Management:
Adopted ISO9001 management practices.
Certified to ISO9001-2000 since 2002.
All staff trained in Total Quality Management (TQM).
5.Comprehensive Quality Control:
Full ISO9001 compliance across R&D, production, marketing, sales, and service.
Unwavering commitment to product quality.
6.Competitive Market Positioning:
A robust marketing network ensuring competitive pricing.
7.Unparalleled Customer Support:
A well-trained service team for prompt and effective support.
Offering maintenance, training, scheme design, and software updates.
8.Long-Term Customer Satisfaction:
Dedicated to providing sustainable and satisfactory customer experiences.
9.Partner with Excellence:
Join us for a partnership built on innovation, quality, and service.
*If you want to know more please check our official website:http://www.genymetertestequipment.com/
