| Brand Name: | GENY |
| Model Number: | YC-1891D |
| MOQ: | 1 |
| Price: | negotiate rates |
| Payment Terms: | T/T,L/C,D/P,T/T |
| Supply Ability: | 5 sets / 1 months |
Guanzhou GENY Electric Co., Ltd. is a prominent manufacturer specializing in energy meter test systems. Formerly known as Guangzhou Yangcheng Science & Technology Enterprises Co., Ltd., the company was founded in 1987. With over 30 years of experience in the energy meter testing industry, we have consistently invested in research and development to enhance our technology and product quality. This commitment enables GENY to deliver superior products and responsive after-sales support to customers both domestically and internationally.
GENY's product portfolio includes stationary energy meter test systems and portable meter testing equipment, all of which strictly adhere to national and international standards such as GB, IEC, CE, and ISO. Owing to their outstanding performance and advanced functionality, more than 8,000 test benches and over 1 million portable standards have been deployed in both Chinese and global markets, earning widespread acclaim and an excellent reputation.
As a privately-owned high-tech enterprise with import and export licensing, GENY has made significant strides in expanding its presence in overseas markets over the past decade. Our products are now exported to more than 40 countries and regions, serving industrial clients, power utilities, and national laboratories alike.
Providing comprehensive technical support and after-sales service to our global customers remains our top priority. GENY is dedicated to delivering high-quality products and building long-term, reliable partnerships. We warmly welcome esteemed customers from around the world to collaborate with us.
| YC1891D-6 | YC1891D-12 | YC1891D-24 | YC1891D-48 | |
| Number of meter positions | 6 | 12 | 24 | 48 |
| Accuracy | 0.05 | |||
| Power Source | YCS-101-250 | YCS-101-600 | YCS-101-1200 | YCS-101-2500 |
| Standard Meter | SZ01A-K3 | |||
| MSVT | HJ200GL-6 | HJ200GL-12 | HJ200GL-24 | HJ200GL-48 |
| QCD | D5 series | |||
| Scanning Head | YCG-2 series | |||
| Voltage | ||||
| Test voltage output | 24V – 288V or customized | |||
| Power of the voltage output | 100VA | 250VA | 500VA | 1000VA |
| Resolution | Better than 0.01% of full scale value of range | |||
| Setting accuracy | Better than 0.05% at the final range value | |||
| Stability | Better than 0.005%/h (integration time 150 s) | |||
| Load regulation from 0-max. load | Better than 0.01% | |||
| Distortion factor | Better than 0.3% for linear resistance load | |||
| Harmonics | 2nd – 21st free programmable | |||
| Current | ||||
| Test current output | 1mA – 100A or customized,Max.200A | 1mA – 100A | ||
| Power of the current output | 150VA | 350VA | 750VA | 1500VA |
| Resolution | Better than 0.01% of full scale value of range | |||
| Setting accuracy | Better than 0.05% at the final range value | |||
| Stability | Better than 0.005%/h (integration time 150 s) | |||
| Load regulation from 0-max. load | Better than 0.01% | |||
| Distortion factor | Better than 0.3% for linear resistance load | |||
| Harmonics | 2nd – 21st free programmable | |||
| Phase angle | ||||
| Range | 0 -- 360° | |||
| Resolution | 0.01° | |||
| Setting accuracy | 0.1° | |||
| Frequency | ||||
| Range | 45Hz – 65Hz | |||
| Resolution | 0.01Hz | |||
| Error display | ||||
| Type of error display | Red LED | |||
| Resolution of the error displays | 8 digits | |||
| Voltage Supply |
220V±10% or customized 50/60Hz±2Hz |
3x220/380V±10% or customized 50/60Hz±2Hz |
||
| Ambient temperature | -10°C -- +40°C | |||
| Relative humidity | 35% -- 85% | |||
